MI1024S-03BRU
Features
:
- 10W Output Power
- Miniature 1”x1” Case
- Wide 4:1 Input Range
- -40°C
- +85°C Operating Temp Range
- 1500VDC Isolation
- Single & Dual Outputs
- Over Voltage Protection
- Industry Standard Pin-Out
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Parameter
Conditions
Min. Typ. Max. Units
Input Voltage Range
24 VDC Input 48 VDC Input
9.0 24 36.0 VDC 18.0 48 75.0 VDC
Reflected Ripple Current
24 VDC Input 48 VDC Input
40 m A
30 m A
Input Filter
Pi Filter
Output
Parameter
Conditions
Min. Typ. Max. Units
Output Voltage Accuracy
0%
- 100% Load
±1.0 ±3.0
%
Line Regulation
Full Load
Vo1
LL HL
Low Line High...
