MI1024S-09BRU Datasheet 4:1 Input Range DC/DC Converters

Manufacturer: MicroPower Direct

Download the MI1024S-09BRU datasheet PDF. This datasheet also includes the MI1024S-03BRU variant, as both parts are published together in a single manufacturer document.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (MI1024S-03BRU-MicroPowerDirect.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number MI1024S-09BRU
Manufacturer MicroPower Direct
File Size 1.71 MB
Description 4:1 Input Range DC/DC Converters
Datasheet download datasheet MI1024S-09BRU Datasheet

Overview

MI1000BRU 10W, Miniautre 1”x1” Case, 4:1 Input Range DC/DC Converters.

Key Features

  • 10W Output Power.
  • Miniature 1”x1” Case.
  • Wide 4:1 Input Range.
  • -40°C - +85°C Operating Temp Range.
  • 1500VDC Isolation.
  • Single & Dual Outputs.
  • Over Voltage Protection.
  • Industry Standard Pin-Out Electrical Specifications Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice. Input Parameter Conditions Min. Typ. Max. Units Input Voltage Range 24 VDC Input 48.
