MLSR7805 Series
Miniature Surface Mount Low Cost, 0.5A POL Switching Regulators
Key Features:
• Efficiency to 95% • 0.5A Output Current • Meets EN 62368 • Miniature SMT Case • Short Circuit Protected • 0.2 mA No-Load Input Current • -40°C to +85°C Operation • Wide Input Range • Adjustable Output Voltage
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change
Output
Parameter
Conditions
Min. Typ. Max. Units
Output Voltage Accuracy, See Note 2
1.5, 1.8, 2.5 & 3.3V Output Models All Other Models
±2.0 ±4.0 %
±2.0 ±3.0
Output Volage Adjust
±10
%
Line Regulation
VIN = Min to Max
±0.2 ±0.4
%
1.5, 1.8, 2.5, 3.3 & 5V Output Models
±0.
