MSR7820-15W Datasheet POL Switching Regulators

Manufacturer: MicroPower Direct

Download the MSR7820-15W datasheet PDF. This datasheet also includes the MSR7820-03W variant, as both parts are published together in a single manufacturer document.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (MSR7820-03W-MicroPowerDirect.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number MSR7820-15W
Manufacturer MicroPower Direct
File Size 2.02 MB
Description POL Switching Regulators
Download MSR7820-15W Download (PDF)

Overview

MSR7820W Series 2A, Single Output Non-Isolated, Wide Input POL Switching Regulators.

Key Features

  • Efficiency to 96%.
  • 2.0A Output Current.
  • Meets EN 62368.
  • Short Circuit Protected.
  • LM78xx Replacement.
  • Wide Input Range.
  • Meets EN 55032.
  • -40ºC to +85ºC Operation Electrical Specifications Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice. Input Parameter Conditions Min. Typ. Max. Units No-Load Input Current Positive Output.
