Datasheet Details
| Part number | MCP1702 |
|---|---|
| Manufacturer | Microchip Technology |
| File Size | 408.17 KB |
| Description | 250mA Low Quiescent Current LDO Regulator |
| Datasheet | MCP1702_MicrochipTechnology.pdf |
|
|
Overview: MCP1702 250 mA Low Quiescent Current LDO Regulator.
| Part number | MCP1702 |
|---|---|
| Manufacturer | Microchip Technology |
| File Size | 408.17 KB |
| Description | 250mA Low Quiescent Current LDO Regulator |
| Datasheet | MCP1702_MicrochipTechnology.pdf |
|
|
|
: The MCP1702 is a family of CMOS low dropout (LDO) voltage regulators that can deliver up to 250 mA of current while consuming only 2.0 µA of quiescent current (typical).
The input operating range is specified from 2.7V to 13.2V, making it an ideal choice for two to six primary cell battery-powered applications, 9V alkaline and one or two cell Li-Ion-powered applications.
The MCP1702 is capable of delivering 250 mA with only 625 mV (typical) of input to output voltage differential (VOUT = 2.8V).
