MCP73832
MCP73832 is Li-Polymer Charge Management Controllers manufactured by Microchip Technology.
- Part of the MCP73831 comparator family.
- Part of the MCP73831 comparator family.
MCP73831/2
Miniature Single-Cell, Fully Integrated Li-Ion, Li-Polymer Charge Management Controllers
Features
- Linear Charge Management Controller:
- Integrated Pass Transistor
- Integrated Current Sense
- Reverse Discharge Protection
- High-Accuracy Preset Voltage Regulation: + 0.75%
- Four Voltage Regulation Options:
- 4.20V, 4.35V, 4.40V, 4.50V
- Programmable Charge Current: 15 mA to 500 mA
- Selectable Preconditioning:
- 10%, 20%, 40%, or Disable
- Selectable End-of-Charge Control:
- 5%, 7.5%, 10%, or 20%
- Charge Status Output
- Tri-State Output
- MCP73831
- Open-Drain Output
- MCP73832
- Automatic Power-Down
- Thermal Regulation
- Temperature Range: -40°C to +85°C
- Packaging:
-...
