TC4420 Datasheet (tc4420 /tc4429) 6a High-speed MOSFET Drivers

Manufacturer: Microchip Technology

Overview: TC4420 TC4429 6A HIGH-SPEED MOSFET DRIVERS.

This datasheet includes multiple variants, all published together in a single manufacturer document.

General Description

The TC4420/4429 are 6A (peak), single output MOSFET drivers.

The TC4429 is an inverting driver (pin-compatible with the TC429), while the TC4420 is a non-inverting driver.

These drivers are fabricated in CMOS for lower power, more efficient operation versus bipolar drivers.

Key Features

  • s s s s s s s s s s s s Latch-Up Protected Will Withstand >1.5A Reverse Output Current Logic Input Will Withstand Negative Swing Up to 5V ESD Protected 4kV Matched Rise and Fall Times 25nsec High Peak Output Current 6A Peak Wide Operating Range 4.5V to 18V High Capacitive Load Drive 10,000pF Short Delay Time 55nsec Typ. Logic High Input, Any Voltage 2.4V to VDD Low Supply Current With Logic "1" Input 450µA Low Output Impedance 2.5Ω Output Voltage Swing to Within 25mV of Ground or VDD.
