ATmega2561 - 8-bit Microcontroller

Product Overview

Microchip

📥 Download Datasheet

ATmega2561 8-bit Microcontroller by Microchip - Datasheet Preview — Datasheet preview – ATmega2561

Datasheet Details

Part number	ATmega2561
Manufacturer	Microchip
File Size	4.68 MB
Description	8-bit Microcontroller
Datasheet	ATmega2561 Datasheet
Note	This datasheet PDF includes multiple part numbers: ATmega2561, ATmega640. Please refer to the document for exact specifications by model.
Additional preview pages of the ATmega2561 datasheet.

Product details

Features

High Performance, Low Power AVR® 8-Bit Microcontroller.
Advanced RISC Architecture.
135 Powerful Instructions.
Most Single Clock Cycle Execution.
32 × 8 General Purpose Working Registers.
Fully Static Operation.
Up to 16 MIPS Throughput at 16MHz.
On-Chip 2-cycle Multiplier.
High Endurance Non-volatile Memory Segments.
64K/128K/256KBytes of In-System Self-Programmable Flash.
4Kbytes EEPROM.
