rfPIC12F675K
rfPIC12F675K is 20-Pin FLASH-Based 8-Bit CMOS Microcontroller manufactured by Microchip Technology.
Features
:
- Memory
- 1024 x 14 words of FLASH program memory
- 128 x 8 bytes of EEPROM data memory
- 64 x 8 bytes of SRAM data memory
- 100,000 write FLASH endurance
- 1,000,000 write EEPROM endurance
- FLASH/data EEPROM retention: > 40 years
- Programmable code protection
- 6 I/O pins with individual direction control, weak pull-ups, and interrupt-on-pin change
- High current sink/source for direct LED drive
- Analog parator: 16 internal reference levels
- Analog-to-Digital Converter: 10 bits, 4 channels
- Timer0: 8-bit timer/counter with 8-bit prescaler
- Timer1: 16-bit timer/counter with 3-bit prescaler
- Timer1 can use LP oscillator in INTOSC mode
- 5 µs wake-up from SLEEP typical with VDD = 3V
- In-Circuit Serial Programming TM (ICSPTM)
Low Power Features
:
- Low power consumption: (typical with VDD = 3V)
- 14 m A transmitting +6 d Bm at 434 MHz
- 4 m A transmitting -15 d Bm at 434 MHz
- 500 µA, 4.0 MHz INTOSC
- 0.6 µA SLEEP with watchdog enabled
- 0.1 µA standby current
- Wide operating voltage range from 2.0
- 5.5V
- Industrial and Extended temperature range
Pin Diagram:
SSOP
GP5/T1CKI/OSC1/CLKIN GP4/T1G/OSC2/CLKOUT
GP3/MCLR/VPP RFXTAL RFEN REFCLK PS VDDRF VSSRF
- 1
20 rf...
