Microsemi 2N2219A
NPN-SWITCHIN SILICON TRANSISTOR
- Max Operating Temp : 200°C
- Min Operating Temp : -55°C
Source:
Octopart
| Part No. | 2N2219A |
|---|---|
| Datasheet | 2N2219A Download |
| Manufacturer |  Microsemi |
| Description | NPN-SWITCHIN SILICON TRANSISTOR |
| Buy | Stock & Price |
ABSOLUTE MAXIMUM RATINGS
(TC = +25°C unless otherwise noted) Parameters / Test Conditions Symbol 2N2218 2N2218A; L 2N2219 2N2219A; L Collector-Emitter Voltage VCEO 30 50 Collector-Base Voltage VCBO 60 75 Emitter-Base Voltage VEBO 5.0 6.0 Collector Current Total Power Dissipation @ TA = +25°C (1) @ TC = +25°C (2) Operating & Storage Junction Temp. Range IC PT Top, Tstg 800 0.8 3.0 -55 to +200 Unit Vdc Vdc Vdc mA W W °C THERMAL CHARACTERISTICS Parameters / Test Conditions Symbol Thermal Resistance, Junction-to-Case RθJC Note: (1) Derate linearly 4.6mW/°C above TA > +25°C (2) Derate linearly 17.0mW/°C above TC > +25°C Value 59 Unit °C/WELECTRICAL CHARACTERISTICS
(TA = +25°C, unless otherwise noted) Parameters / Test Conditions Symbol Min. Max. Unit OFF CHARACTERTICS Collector-Emitter Breakdown Voltage IE = 10mAdc 2N2218; 2N2219 2N2218A; 2N2219A; L V(BR)CEO 30 50 Vdc Emitter-Base Cutoff Current VEB = 5.0Vdc VEB = 6.0Vdc VEB = 4.0Vdc Collector-Base Cutoff Current VCE = 30Vdc VCE = 50Vdc 2N...
