2N3903 Datasheet PDF

MAXIMUM RATINGS

Rating Symbol Value Collector – Emitter Voltage Collector – Base Voltage Emitter – Base Voltage Collector Current — Continuous Total Device Dissipation @ TA = 25°C Derate above 25°C VCEO VCBO VEBO IC PD 40 60 6.0 200 625 5.0 Total Device Dissipation @ TC = 25°C Derate above 25°C PD 1.5 12 Operating and Storage Junction Temperature Range TJ, Tstg – 55 to +150 THERMAL CHARACTERISTICS(1) Characteristic Symbol Max Thermal Resistance, Junction to Ambient RqJA 200 Thermal Resistance, Junction to Case RqJC 83.3

ELECTRICAL CHARACTERISTICS

(TA = 25°C unless otherwise noted) Characteristic OFF CHARACTERISTICS Collector – Emitter Breakdown Voltage (2) (IC = 1.0 mAdc, IB = 0) Collector – Base Breakdown Voltage (IC = 10 mAdc, IE = 0) Emitter – Base Breakdown Voltage (IE = 10 mAdc, IC
