Multicomp N0603F474ZNT
The outline of MLCC Size Inch (mm) 0603 (1608) L (mm) 1.6 ±0.1 1.6 +0.15/-0.1 W (mm) 0.8 ±0.1 0.8 +0.15/-0.1 2 ±0.15 0805 (2012) 2 ±0.2 1.25 ±0.1 1.25 ±0.2 3.2 ±0.15 1.6 ±0.15 1206 (3216) 3.2 +0.3/-0.1 1.6 +0.3/0.1 T (mm)/Symbol 0.8 ±0.07 S 0.8 +0.15/-0.1 X 0.6 ±0.1 A 0.8 ±0.1 B 1.25 ±0.1 D 1.25 ±0.2 I 0.8 ±0.1 B 0.95 ±0.1 C 1.15 ±0.15 J 1.25 ±0.1 D 1.6 ±0.2 G 1.6 +0.3/-0.1 P Remark - - # # # # # # # Reflow soldering only is recommended.| Part No. | N0603F474ZNT |
|---|---|
| Datasheet | N0603F474ZNT Download |
| Manufacturer |  Multicomp |
| Description | Multilayer SMD Ceramic Capacitors |
| Buy | Stock & Price |
DESCRIPTION
: MLCC consists of a conducting material and electrodes. To manufacture a chip-type SMT and achieve miniaturization, high density and high efficiency, ceramic condensers are used. MLCC is made by NP0, X7R and Y5V dielectric material and which provides product with high electrical precision, stability and reliability.FEATURES
:● A wide selection of sizes is available (0603, 0805, 1206).
● High capacitance in given case size.
● Capacitor with lead-free termination (pure Tin).
APPLICATIONS
:● For general digital circuit.
● For power supply bypass capacitors.
● For consumer electronics.
● For telecommunication. External Dimensions: MB (mm) 0.4 ±0.15 0.5 ±0.2 0.6 ±0.2 Newark.com/multicomp-pro Farnell.com/multicomp-pro Element14.com/multicomp-pro Page <1> 23/09/19 V1.0 Multilayer SMD Ceramic Capacitors General Purpose Series General Electrical Data: Dielectric Size Capacitance* Capacitance tolerance** Rated voltage (WVDC) DF (Tan δ)* Insulation resistance at Ur Operating temperat...
