PS2501L-4 Datasheet Photocoupler

Manufacturer: NEC (now Renesas Electronics)

Overview: DATA SHEET PHOTOCOUPLER PS2501-1,-2,-4, PS2501L-1,-2,-4 HIGH ISOLATION VOLTAGE SINGLE TRANSISTOR TYPE MULTI PHOTOCOUPLER SERIES −NEPOC TM.

General Description

The PS2501-1, -2, -4 and PS2501L-1, -2, -4 are optically coupled isolators containing a GaAs light emitting diode and an NPN silicon phototransistor.

The PS2501-1, -2, -4 are in a plastic DIP (Dual In-line Package) and the PS2501L-1, -2, -4 are lead bending type (Gull-wing) for surface mount.

Key Features

  • High isolation voltage (BV = 5 000 Vr. m. s. ).
  • High collector to emitter voltage (VCEO = 80 V).
  • High-speed switching (tr = 3 µs TYP. , tf = 5 µs TYP. ).
  • Ordering number of taping product: PS2501L-1-E3, E4, F3, F4, PS2501L-2-E3, E4.
  • UL approved: File No. E72422 (S).
