Automotive Capacitive Sensor Conditioner with SENT Interface Datasheet (EN) 1.0 Product Overview The NSC9264 is a highly integrated and AEC-Q100 qualified IC for capacitive sensor conditioning. The NSC9264 integrates a C/V converter, a 24-bit primary signal measurement channel, a 24-bit temperature measurement channel and a sensor calibration logic. With the calibration algorithm built in the internal MCU, the NSC9264 supports to pensate sensor offset, sensitivity, temperature drift up to 2nd order , and nonlinearity up to the 3rd order. The calibration coefficients are stored in a 64-Byte EEPROM that can be programmed multiple times. The NSC9264 also supports Over-voltage and...
