NTP8825 Description
The NTP8825 is a single chip full digital audio amplifier including power stages for stereo amplifier systems. NTP8825 is integrated with versatile digital audio signal processing functions, high-performance, high-fidelity fully digital PWM modulator and two high-power full-bridge MOSFET power stages. The NTP8825 receives digital serial audio data with sampling frequencies from 8kHz through 192kHz.
NTP8825 Key Features
- 2 CH Stereo (20W x 2 BTL @24V, 6Ω)
- 2.1CH (10W x 2 + 20W @24V, 6Ω)
- SDATA Generator (I2S output)
- Wide Operating Supply Voltage Range
- Floating Point Operation
- 25 Programmable Bi-Quad Filters
- Speaker pensation
- LPF, HPF
- Parametric Equalizer
- Loudness Control
