NJM4558E - DUAL OPERATIONAL AMPLIFIER

Product Overview

📥 Download Datasheet

Datasheet preview – NJM4558E

Datasheet Details

Part number NJM4558E
Manufacturer New Japan Radio
File Size 120.96 KB
Description DUAL OPERATIONAL AMPLIFIER
Datasheet download datasheet NJM4558E Datasheet
Note This datasheet PDF includes multiple part numbers: NJM4558E, NJM4558.
Please refer to the document for exact specifications by model.
Additional preview pages of the NJM4558E datasheet.

Product details

Description

The NJM4558 is a dual high-gain operational amplifier with internal compensation circuit and constructed on a single silicon chip.It offers excellent characteristics by combining the parameters adjusted for a monolithic chip.The channel separation characteristic is suitable for measuring instruments. PACKAGE OUTLINE NJM4558D ( DIP8 ) NJM4558M ( DMP8 )

Features
