SOT23SM712S712
FEATURE
- Peak power dissipation 400W (8/20µs)
- Transient protection for asymmetrical data lines
- IEC61000-4-2 (ESD) ±15k V (air), ±8k V (contact)
- IEC61000-4-4 (EFT) 40A (5/50ns)
- IEC61000-4-5 (Lightning) 12A (8/20µs)
- Protects Two +12V to -7V lines
- Low clamping voltage
- Low leakage current
- Low capacitance
- Solid-state silicon avalanche technology
- Meet MSL 1 requirement
APPLICATION
- Protection of RS-485 transceivers with extended
- mon-mode range
- Security system
- Automatic Teller Machines
- HFC systems
- Networks
PART CODE GUIDE
SOT23 1
SM712 2
Request For Quotation
1) SOT23: SMD Plastic-Encapsulate ESD Protection Diodes, SOT-23 series, 3 pads
2) SM712: Type code for original part number SM712
3) S: Package code, Package in Tape/Reel, 3000pcs/Reel
4) 712: Marking code for “712 ” or “C72”on the case surface, Different Marking for different specification.
