1N5817 Datasheet SCHOTTKY BARRIER RECTIFIER

Manufacturer: onsemi

📥 Download Datasheet

1N5817 schottky barrier rectifier by onsemi - Datasheet Preview

Datasheet Details

Part number	1N5817
Manufacturer	onsemi
File Size	194.79 KB
Description	SCHOTTKY BARRIER RECTIFIER
Download	1N5817 Download (PDF)

Overview

Axial Lead Rectifiers SCHOTTKY BARRIER RECTIFIERS 1.0 AMPERE 20, 30 and 40 VOLTS 1N5817, 1N5818, 1N5819 This series employs the Schottky Barrier principle in a large area metal−to−silicon power diode.

Key Features

chrome barrier metal, epitaxial construction with oxide passivation and metal overlap contact. Ideally suited for use as rectifiers in low.
voltage, high.
frequency inverters, free wheeling diodes, and polarity protection diodes. Features.
Extremely Low VF.
Low Stored Charge, Majority Carrier Conduction.
Low Power Loss/High Efficiency.
These are Pb.
Free Devices.
Mechanical Characteristics:.
Case: Epoxy, Molded.
Weigh.
