MC34063A Key Features
- Operation from 3.0 V to 40 V Input
- Low Standby Current
- Current Limiting
- Output Switch Current to 1.5 A
- Output Voltage Adjustable
- Frequency Operation to 100 kHz
- Precision 2% Reference
- NCV Prefix for Automotive and Other
- Part: MC34063A
- Manufacturer: onsemi (official site)
- Size: 1.44 MB
Other MC34063A Datasheets
| Manufacturer | Part Number | Description |
|---|---|---|
HTC KOREA |
MC34063A | DC-DC Converter Controller |
Motorola Semiconductor |
MC34063A | DC-to-DC Converter Controller |
AIC |
MC34063A | DC/DC CONVERTER CONTROLLER |
Fairchild |
MC34063A | SMPS Controller |
STMicroelectronics |
MC34063A | DC-DC CONVERTER CONTROL CIRCUITS |
MC34063A Description
Inverting Regulator - Buck, Boost, Switching 1.5 A MC34063A, MC33063A, SC33063A, NCV33063A The MC34063A Series is a monolithic control circuit containing the primary functions required for DC−to−DC converters. These devices consist of an internal temperature pensated reference, parator, controlled duty cycle oscillator with an active current limit circuit, driver and high current output switch. This series was...
MC34063A Applications
- Operation from 3.0 V to 40 V Input
