MC74LVX257 - Quad 2-Channel Multiplexer with 3-State Outputs

Datasheet Summary

Features

http://onsemi. com.

ON Semiconductor

📥 Download Datasheet

Datasheet Details

Part number	MC74LVX257
Manufacturer	ON Semiconductor
File Size	241.58 KB
Description	Quad 2-Channel Multiplexer with 3-State Outputs
Datasheet	MC74LVX257 Datasheet
Additional preview pages of the MC74LVX257 datasheet.

📁 Similar Datasheet

MC74LVX240 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX244 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX245 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX00 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX02 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX04 - Hex Inverter (Motorola)
MC74LVX08 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX125 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX138 - LOW-VOLTAGE CMOS (Motorola)
MC74LVX14 - Hex Schmitt Inverter (Motorola)

Other Datasheets by ON Semiconductor

MC74LVX259 - 8-Bit Addressable Latch/1-of-8 Decoder CMOS Logic Level Shifter
MC74LVX240 - Octal Bus Buffer Inverting
MC74LVX244 - Octal Bus Buffer
MC74LVX245 - Octal Bus Transceiver
MC74LVX00 - Quad 2-Input NAND Gate
MC74LVX02 - Quad 2-Input NOR Gate
MC74LVX04 - Hex Inverter
MC74LVX08 - Quad 2-Input NAND Gate

Full PDF Text Transcription

Click to expand full text

www.DataSheet4U.com MC74LVX257 Quad 2−Channel Multiplexer with 3−State Outputs The MC74LVX257 is an advanced high speed CMOS quad 2−channel multiplexer fabricated with silicon gate CMOS technology. It consists of four 2−input digital multiplexers with common select (S) and enable (OE) inputs. When (OE) is held High, selection of data is inhibited and all the outputs go Low. The select decoding determines whether the A or B inputs get routed to the corresponding Y outputs. The inputs tolerate voltages up to 7.0 V, allowing the interface of 5.0 V systems to 3.0 V systems. Features http://onsemi.com MARKING DIAGRAMS 16 • • • • • • • • • • • • High Speed: tPD = 4.5 ns (Typ) at VCC = 3.
