MM5Z4V7T1G Datasheet Zener Voltage Regulator

Manufacturer: onsemi

Overview: Zener Voltage Regulators 500 mW SOD−523, Standard Tolerance Series MM5ZxxxT1G Series, SZMM5ZxxxT1G Series This series of Zener diodes is packaged in a SOD−523 surface mount package. They are designed to provide voltage regulation protection and are especially attractive in situations where space is at a premium. They are well suited for applications such as cellular phones, hand held portables, and high density PC boards.

This datasheet includes multiple variants, all published together in a single manufacturer document.

Key Features

  • Standard Zener Breakdown Voltage Range.
  • 2.4 V to 75 V.
  • Standard Tolerance Series.
  • Steady State Power Rating of 500 mW.
  • Small Body Outline Dimensions: 0.047″ x 0.032″ (1.20 mm x 0.80 mm) Low Body Height: 0.028″ (0.7 mm).
  • ESD Rating of Class 3 (> 16 kV) per Human Body Model.
  • SZ Prefix for Automotive and Other.
