MMUN2135L Overview
The Bias Resistor Transistor (BRT) contains a single transistor with a monolithic bias network consisting of two resistors; a series base resistor and a base−emitter resistor. The BRT eliminates these individual ponents by integrating them into a single device.
MMUN2135L Key Features
- Simplifies Circuit Design
- Reduces Board Space
- Reduces ponent Count
- S and NSV Prefix for Automotive and Other
