MSQA6V1W5T2G
Features
- Low Clamping Voltage
- Stand Off Voltage 3 V
- Low Leakage < 1 m A @ 3 V
- SC- 88A Package Allows Four Separate Unidirectional
Configurations
- IEC1000- 4- 2 Level 4 ESD Protection
- SZ Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC- Q101 Qualified and PPAP Capable
- Pb- Free Package is Available-
Mechanical Characteristics:
- Void Free, Transfer- Molded, Thermosetting Plastic Case
- Corrosion Resistant Finish, Easily Solderable
- Package Designed for Optimal Automated Board Assembly
- Small Package Size for High Density Applications
SCALE 2:1
SC- 88A/SOT- 323 CASE 419A
MARKING DIAGRAM
61 M G G
61 = Device Code M = Date Code G = Pb- Free Package
(Note: Microdot may be in either location)
ORDERING INFORMATION
Device MSQA6V1W5T2G
Package
SC- 88A (Pb- Free)
Shipping†
3000 / Tape & Reel
DISCONTINUED (Note 1)
SZMSQA6V1W5T2G SC- 88A (Pb- Free)
3000 / Tape & Reel
†For information on tape and reel specifications,...
