NTGS3136P
NTGS3136P is P-Channel Power MOSFET manufactured by onsemi.
Features
- Low RDS(on) in TSOP- 6 Package
- 1.8 V Gate Rating
- Fast Switching
- NV Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC- Q101 Qualified and PPAP Capable
- These Devices are Pb- Free, Halogen Free/BFR Free and are Ro HS pliant
Applications
- Optimized for Battery and Load Management Applications in
Portable Equipment
- High Side Load Switch
- Switching Circuits for Game Consoles, Camera Phone, etc.
MAXIMUM RATINGS (TJ = 25°C unless otherwise stated)
Parameter
Symbol Value Unit
Drain- to- Source Voltage
VDSS
- 20
Gate- to- Source Voltage
$8.0
Continuous Drain Current (Note 1)
Steady TA = 25°C
State TA = 85°C
- 5.1
- 3.6
A t v 5 s TA = 25°C
- 5.8
Power Dissipation (Note 1)
Steady
State TA = 25°C tv5s
1.25 W
Continuous Drain Current (Note 2)
Power Dissipation (Note 2)
TA =...
