MOSFET - Power, Single P-Channel, SO8-FL
-30 V, 1.4 mW, -263 A
NTMFS002P03P8Z
Features
• Ultra Low RDS(on) to Improve System Efficiency • Advanced Package Technology in 5x6mm for Space Saving and
Excellent Thermal Conduction
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
Typical Applications
• Power Load Switch • Protection: Reverse Current, Over Voltage, and Reverse Negative
Voltage
• Battery Management
MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
Parameter
Symbol Value Unit
Drain−to−Source Voltage
Gate−to−Source Voltage
Continuous Drain Current RqJC (Notes 1, 2)
Power Dissipation RqJC (Notes 1, 2)
Steady State
TC = 25°C TC = 85°C TC = 25°C
VDSS VGS ID
PD
−30
V
"25 V
−263 A
−189
138.
