NVTFS5C460NL
NVTFS5C460NL is 40V 74A N-Channel Power MOSFET manufactured by onsemi.
Features
- Small Footprint (3.3 x 3.3 mm) for pact Design
- Low RDS(on) to Minimize Conduction Losses
- Low Capacitance to Minimize Driver Losses
- NVTFS5C460NLWF
- Wettable Flanks Product
- AEC-Q101 Qualified and PPAP Capable
- These Devices are Pb-Free and are Ro HS pliant
MAXIMUM RATINGS (TJ = 25 C unless otherwise noted)
Parameter
Symbol Value Unit
Drain-to-Source Voltage
VDSS
Gate-to-Source Voltage
20
Continuous Drain Current Rq JC (Notes 1, 2, 3, 4)
TC = 25 C
Steady TC = 100 C
Power Dissipation Rq JC (Notes 1, 2, 3)
State TC = 25 C
TC = 100 C
Continuous Drain Current Rq JA (Notes 1, 3, 4)
Power Dissipation Rq JA (Notes 1, 3)
TA = 25 C
Steady TA = 100 C
State TA = 25 C
TA = 100 C
Pulsed Drain Current TA = 25 C, tp = 10 ms
Operating Junction and Storage Temperature Range
TJ,...
