NL27WZ86 Description
Dual 2-Input Exclusive-OR Gate NL27WZ86 The NL27WZ86 is a high performance dual 2-input Exclusive-OR Gate operating from a 1.65 V to 5.5 V supply.
NL27WZ86 Key Features
- Designed for 1.65 V to 5.5 V VCC Operation
- 2.9 ns tPD at VCC = 5 V (typ)
- Inputs/Outputs Overvoltage Tolerant up to 5.5 V
- IOFF Supports Partial Power Down Protection
- Source/Sink 24 mA at 3.0 V
- Available in US8 and UQFN8 Packages
- Chip plexity < 100 FETs
- Q Suffix for Automotive and Other
