SPLC100B1 Datasheet PDF

ORISE SPLC100B1

The SPLC100B1 is a Liquid Crystal Display driver that contains two sets of 20-bit bi-directional shift registers, 20 data latch flip-flops and 20 Liquid Crystal Display drivers. It also features 40-channel outputs that can be applied as common or segment driver. The SPLC100B1 receives serial display data from a display control LSI, converts it into parallel data and supplies liquid crystal display waveforms to the liquid crystal.

Part No.	SPLC100B1
Datasheet	SPLC100B1 Download
Manufacturer	ORISE
Description	40-Channel SEG/COM LCD Driver
Buy	Stock & Price

GENERAL DESCRIPTION

FEATURES

Liquid Crystal Display driver with serial/parallel conversion function. Serial transfer facilitates board design. Capable of interfacing to liquid crystal display controllers: HD43160AH, HD61830, HD44780, HD44790, SPLC780 40 internal LCD drivers. Internal serial/parallel conversion circuits: — 20-bit shift register × 2 — 20-bit latch × 2 Power supply: — Internal logic: 2.7V - 5.5V — Liquid crystal display driver circuit: 3.0V - 8V CMOS process. Package form: 64 QFP or bare chip available 3. ORDERING INFORMATION Product Number SPLC100B1-C SPLC100B1-HQ041 Package Type Chip form Green Package form - QFP 64L 4. BLOCK DIAGRAM Y1 Y20 V1,V2 V3,V4 CL1 DL1 CL2 DL2 FCS M V1,V2 V5,V6 LCD Drivers Latch signal Data 20-bit latch Shift signal 20-bit bidirectional shift register Switching circuit 20-bit bidirectional shift register Data 20-bit latch Shift direction Data Data Shift direction LCD Drivers SHL1 DR1 DR2 SHL2 Y21 Y40 © ORISE Technology Co., Ltd.
