GENERAL DESCRIPTION
2. FEATURES
Character generator ROM: 10880 bits ─ Character font 5 x 8 dots: 192 characters ─ Character font 5 x 10 dots: 64 characters 4 type CGROM mode, Max. 256 characters can be used. Character generator RAM: 512 bits ─ Character font 5 x 8 dots: 8 characters ─ Character font 5 x 10 dots: 4 characters 3. ORDERING INFORMATION Product Number SPLC782A1-NnnV-C Note1: Code number is assigned for customer. Note2: Code number (N = A - Z or 0 - 9, nn = 00 - 99); version (V = A - Z). Provide connecting to 4-bit or 8-bit MPU Direct driver for LCD: 16 COMs x 80 SEGs 80-channel Bi-Direction segment driver 16-channel Bi-direction common driver Duty factor (selected by program): ─ 1/8 duty: 1 line of 5 x 8 dots ─ 1/11 duty: 1 line of 5 x 10 dots ─ 1/16 duty: 2 lines of 5 x 8 dots / line LCD type-A, type-B waveform can be selected. Built-in power on automatic reset circuit Built-in oscillator circuit (with internal resistor) Built-in Bias resistor Support external clock operation Package form: Au bump chip Package Type Chip form with gold bump 4.
ORISE
