GW Q9LR35.PM DATASHEET OSCONIQ™ S 5050 GW Q9LR35.PM The latest QFN cast 5050 LED version adds to its impressive 5050 line-up of high efficacy performance bined with DLC Premium Lifetime. This OSCONIQ S 5050 leadframe package brings its Robustness stability to another level with a Superior Corrosion protection that further enhance the suitability for Outdoor Professional lighting. Applications - Indoor Lighting - Outdoor & Industrial Lighting  Features - Package: white SMT package, colored diffused resin - Typ. Radiation: 120° (Lambertian emitter) - Color temperature: 1800K - 6500K - CRI: 70 (min.), R9: -50 (min.) - ESD: 8 k V acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B) - Luminous Flux: typ. 234 lm @ 4000 K - Luminous efficacy: typ. 238 lm/W @ 4000 K  2 | Version 1.1 | 2025-06-18 GW Q9LR35.PM DATASHEET Ordering Information  Type GW Q9LR35.PM-L8M8-XX512-1 GW Q9LR35.PM-M2N1-XX510-1 GW Q9LR35.PM-M4N1-XX58-1 GW Q9LR35.PM-M4N3-XX57-1 GW Q9LR35.PM-M5N3-XX56-1 GW Q9LR35.PM-M6N5-XX55-1 GW Q9LR35.PM-M6N5-XX53-1 GW Q9LR35.PM-M5N4-XX52-1 GW Q9LR35.PM-M5N4-XX51-1 Color temperature  1800 K 2200 K 2700 K 3000 K 3500 K 4000 K 5000 K 5700 K 6500 K Luminous Flux 1) IF = 180 m A ΦV 160 ... 260 lm 190 ... 290 lm 210 ... 290 lm 210 ... 310 lm 220 ... 310 lm 230 ... 330 lm 230 ... 330 lm 220 ... 320 lm 220 ... 320 lm Ordering Code Q65113A9315 Q65113A9314 Q65113A9316 Q65113A9318 Q65113A9317 Q65113A9322 Q65113A9321 Q65113A9320...
