SFH4735 - IR broad band emitter

Features

  • SMD epoxy package.
  • ThinGaN (UX:3).
  • Wide viewing angle of 120°.
  • Improved Corrosion Robustness.
  • Low thermal resistance (Max. 9 K/W).

📥 Download Datasheet

Datasheet preview – SFH4735

Datasheet Details

Part number SFH4735
Manufacturer OSRAM
File Size 527.08 KB
Description IR broad band emitter
Datasheet download datasheet SFH4735 Datasheet
Additional preview pages of the SFH4735 datasheet.

📁 Similar Datasheet

  • SFH400 - GaAs Infrared Emitter (Siemens Semiconductor Group)
  • SFH401 - GaAs Infrared Emitter (Siemens)
  • SFH402 - GaAs-IR-Lumineszenzdiode GaAs Infrared Emitter (Siemens Semiconductor Group)
  • SFH405 - GaAs Infrared Emitter (Siemens Semiconductor Group)
  • SFH407 - INFRARED EMITTER (Siemens Semiconductor Group)
  • SFH409 - GaAs Infrared Emitter (Siemens Semiconductor Group)
  • SFH415 - GaAs Infrared Emitters (Siemens Semiconductor Group)
  • SFH416 - GaAs Infrared Emitters (Siemens)
  • SFH420 - GaAs-IR-Lumineszenzdiode in SMT-Gehause GaAs Infrared Emitter in SMT Package (Siemens Semiconductor Group)
  • SFH420 - (SFH420 / SFH425) GaAs Infrared Emitter (OSRAM GmbH)
Other Datasheets by OSRAM

Full PDF Text Transcription

Click to expand full text
2017-02-21 OSLON Black Flat (IR broad band emitter) - 120° Version 1.1 SFH 4735 Features: • SMD epoxy package • ThinGaN (UX:3) • Wide viewing angle of 120° • Improved Corrosion Robustness • Low thermal resistance (Max. 9 K/W) Applications • Illumination source for spectroscopy Notes Depending on the mode of operation, these devices emit highly concentrated non visible infrared light which can be hazardous to the human eye. Products which incorporate these devices have to follow the safety precautions given in IEC 60825-1 and IEC 62471. Ordering Information Type: SFH 4735 Total Radiant Flux Φe [mW] IF = 350 mA, tp = 20 ms 200 Ordering Code Q65111A9885 Note: Measured with integrating sphere. 2017-02-21 1 Version 1.
