OD5010
OD5010 Series
DC Fans
- 5, 12, 24V 50mm x 10.5mm (2.0” x 0.4”)
Frame Impeller Connection
Motor
Bearing System Dielectric Strength Insulation Resistance
PBT, UL94 V-0 Plastic
PBT, UL94 V-0 Plastic
2x Lead Wires, 26 AWG
Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected
Ball Bearings
500VDC/min, <1m A
≥10M Ohm @ 500 VDC
Operating Temperature -20°C ~ +65°C
Storage Temperature -20°C ~ +75°C
Life Expectancy 70,000 Hours (L10 at 40°C)
Available Options: Tachometer Output PWM Speed Control Input Alarm Output Sealed Sleeve Bearings IP Ratings
Weight: 0.07 lbs.
Part Number
OD5010-05HB OD5010-05MB OD5010-05LB OD5010-12HB OD5010-12MB OD5010-12LB OD5010-24HHB OD5010-24HB OD5010-24MB OD5010-24LB
Rated Voltage (Volts DC)
5 5 5 12 12 12 24 24 24 24
Voltage Range (Volts DC) 4.5 ~ 5.5 4.5 ~ 5.5 4.5 ~ 5.5 8 ~ 13.8 8 ~ 13.8 8 ~ 13.8 20 ~ 26.4 20 ~ 26.4 20 ~ 26.4 20 ~ 26.4
Input Power (Watts) 1.05 1.05 0.95 1.20 1.08 0.84 2.40 1.92 1.68 1.44
Rated Current...
