PADAUK PFS122
The PFS122 is an MTP-based 8-bit microcontroller with 12-bit R-Type ADC. It employs RISC architecture and all the instructions are executed in one cycle except that some instructions are two cycles that handle indirect memory access.| Part No. | PFS122 |
|---|---|
| Datasheet | PFS122 Download |
| Manufacturer | PADAUK |
| Description | 8bit MTP Type MCU |
| Buy | Stock & Price |
FEATURES
1.1. SpecialFEATURES
● General purpose series● Not supposed to use in AC RC step-down powered or high EFT requirement applications. PADAUK assumes no liability if such kind of applications can not pass the safety regulation tests.
● Operating temperature range: -40°C ~ 85°C 1.2. System
FEATURES
● 2KW MTP program memory (programming cycle at least 1,000 times)● 128 Bytes data SRAM
● One hardware 16-bit timer
● Two hardware 8-bit timers with PWM generation
● One hardware comparator
● Bandgap circuit to provide 1.20V reference voltage
● Up to 12-channel 12-bit resolution R-type* ADC with one channel comes from internal bandgap voltage *Note: R-Type ADC means Resistive type ADC. Its linearity (INL&DNL), heat stability and power noise rejection would not be as good as the C-Type ADC which is built in the PMS13x series.
● Max. 14 IO pins with optional pull-high / pull-low resistor
● Every IO pin can be configured to enable wake-up function
● Clock sources: IHRC, ILRC and EOSC (XT...
