P6CG244R8ZS
Telefon: +49 (0) 6135 931069 Telefax: +49 (0) 6135 931070
.peak-electronics.de info@peak-electronics.de
M2 SERIES P6CG-XXXXZS 1KV ISOLATED 0,6
- 1 W REGULATED DUAL SPLIT OUTPUT SIP7
Available Inputs:
5, 12 and 24 VDC
Available Outputs:
3.0, 3.3, 4.85 and 5 VDC Other specifications please enquire.
Electrical Specifications
(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)
Input Specifications Voltage range Filter Isolation Specifications Rated voltage Leakage current Resistance Capacitance Output Specifications Voltage accuracy Ripple and noise (at 20 MHz BW) Short circuit protection Line voltage regulation Load voltage regulation Temperature coefficient General Specifications Efficiency Switching frequency Environmental Specifications Operating temperature (ambient) Storage temperature Derating Humidity Cooling Physical Characteristics Dimensions SIP
Weight Case material
+/- 10 % Capacitors
1000 VDC 1 m A 109 Ohm 80 p F typ.
+/- 1 %, max. 50...
