C-1021E
FEATURES
26.00mm (1.0 inch ) DIGIT HEIGHT
MON CATHODE
I.C. PATIBLE LOW POWER CONSUMPTION
M Raw Material : Ga Al In P/Ga As
ABSOLUTE MAXIMUM RATING : ( Ta = 25°C )
O SYMBOL
PARAMETER
PD Power Dissipation Per Segment
.C VR Reverse Voltage Per Segment(DP)
IAF Continuous Forward Current Per Segment
Peak Forward Current Per Segment
D IPF (1/10 Duty Cycle,0.1ms Pulse Width)
－ Derating Linear From 25°C Per Segment
E Topr Operating Temperature Range
IL Tstg Storage Temperature Range
HI.EFFI RED 75
10(5) 25
UNIT m W
V m A
100 m A
0.33 m A/°C
－35°C to 85°C
－35°C to 85°C
ELECTRO-OPTICAL CHARACTERISTICS : ( Ta = 25°C )
M SYMBOL
PARAMETER
U VF Forward Voltage , Per Segment(DP)
IR Reverse Current , Per Segment(DP)
L λP Peak Emission Wavelength EλD Dominant Wavelength
TEST CONDITION
IF = 20m A VR =10 (5)V IF = 20m A IF = 20m A
MIN. TYP. MAX. UNIT
4.2(2.1) 5.6(2.8) V
100 µA
632 nm
622 nm
∆λ Spectral Line Half－Width
IF = 20m A
35...
