L-518EIR1BC
FEATURES
- EXTRA HIGH RADIANT POWER AND RADIANT INBTENSITY
- LOW FORWARD VOLTAGE
- SUITABLE FOR HIGH PULSE CURRENT OPERATIONTENSITY
- HIGH RELIABILITY
- Pb FREE PRODUCTS
CHIP MATERIALS
- Dice Material : Ga Al As/Ga As
- Lens Color : BLUE TRANSPARENT
ABSOLUTE MAXIMUM RATING : ( Ta = 25°C )
SYMBOL
PARAMETER
PD Power Dissipation
VR Reverse Voltage
IF Forward Current
IPF Peak forward current (F=1KHZ,duty=0.1)
Topr Operating Temperature Range
Tstg Storage Temperature Range
UNIT
180 m W
100 m A
800 m A
-25°C to 85°C
-25°C to 85°C
ELECTRO-OPTICAL CHARACTERISTICS : ( Ta = 25°C )
SYMBOL
PARAMETER
TEST MIN. TYP. MAX. UNIT
CONDITION
VF Forward Voltage
IF = 20m A IF = 100m A
1.3 V
1.5 1.8
VFP Peak Forward Voltage
IPF=800m A
2.2 2.5 V
IR Reverse Current
VR =...
