SA555 - Timer

Product Overview

Philips

📥 Download Datasheet

SA555 Timer by Philips - Datasheet Preview — Datasheet preview – SA555

Datasheet Details

Part number	SA555
Manufacturer	Philips
File Size	101.34 KB
Description	Timer
Datasheet	SA555 Datasheet
Additional preview pages of the SA555 datasheet.

SA555 Product details

Description

The 555 monolithic timing circuit is a highly stable controller capable of producing accurate time delays, or oscillation.

In the time delay mode of operation, the time is precisely controlled by one external resistor and capacitor.

Features

Turn-off time less than 2 µs.
Max. operating frequency greater than 500 kHz.
Timing from microseconds to hours.
Operates in both astable and monostable modes.
High output current.
Adjustable duty cycle.
TTL compatible.
Temperature stability of 0.005% per °C.
