GENERAL DESCRIPTION
1.1. Product Overview It supports output interface with parallel or MIPI interface and HD analog video with embedded video DAC. ) 1.2. FEATURES
CIS Input ( MIPI or Parallel Input S - Up to 1920x1080p@60Hz AS - MIPI CSI-2 RAW 10/12/14/16/20 Bits - MIPI CSI-2 1/2/4 Lane @ 600Mbps AM - Parallel 10/12 Bits with H/V Sync r Video Output fo High Quality Free Down Scaling Engine l - 1080p/960p to 960p/720p tia - 1080p/960p/720p to SD (NTSC/PAL) n MIPI or Parallel Output e - Selectable between scaler in and scaler out fid- Up to 1920x1080p@60Hz n- MIPI CSI-2 RAW 10/12 Bits, YUV 16 Bits Co - MIPI CSI-2 1/2/4 Lane @ 450Mbps - Parallel 10/12/16 Bits with H/V/F Sync Analog HD Output - Selectable between scaler in and scaler out - Up to 1920x1080p @30fps - Video DAC with 10 Bits - Bi-directional UTC Image Signal Processing HDR Tone-map BLC, LSC, DPC Rev 0.34 6 Confidential PI6008K 2D Noise Reduction De-mosaic Color / Gamma Correction De-color, Edge Enhancement Contrast & Brightne...
