Datasheet Summary
ADVANCE INFORMATION
DS3634
- 2.0
SL1640 IS FOR MAINTENANCE PURPOSES ONLY AND IS NOT REMENDED FOR NEW DESIGNS
DOUBLE BALANCED MODULATORS
The SL1640 is a double balanced modulator intended for use in radio systems at frequencies up to 75MHz. The SL1640 has an integral output load resistor (Pin 5) together with an emitter follower output (Pin 6).
Features s No External Bias Networks Needed s Easy Interfacing s Choice of Voltage or Current Outputs
Fig.1 Pin connections (top view)
DP8
APPLICATIONS s Mixers In Radio Transceivers s Phase parators s Modulators
QUICK REFERENCE DATA s Supply Voltage: 6V s Conversion Gain: 0dB s Maximum Inputs: 200mV...
