R6504END3
R6504END3 is Nch 650V 4A Power MOSFET manufactured by ROHM.
Nch 650V 4A Power MOSFET
VDSS RDS(on)(Max.)
ID PD
650V 1.050Ω ±4.0A
58W l Features
1) Low on-resistance 2) Fast switching speed 3) Parallel use is easy 4) Pb-free plating ; Ro HS pliant l Outline
TO-252 l Inner circuit
Datasheet l Application Switching l Packaging specifications
Packing
Embossed Tape
Packing code
TL1
Marking
R6504E
Quantity (pcs)
2500 l Absolute maximum ratings (Ta = 25°C ,unless otherwise specified)
Parameter
Symbol
Value
Unit
Drain
- Source voltage Continuous drain current (Tc = 25°C) Pulsed drain current
VDSS ID- 1 IDP- 2
±4.0
±12
Gate
- Source voltage
Static
AC(f＞1Hz)
VGSS
±20
±30
Avalanche current, single pulse Avalanche energy, single pulse Power dissipation (Tc = 25°C) Junction temperature Operating junction and storage temperature range
IAS EAS- 3 PD
Tj...
