S4603
Features
1) Low on-resistance 2) Fast switching speed 3) Fast reverse recovery 4) Easy to parallel 5) Simple to drive
1200V 36mΩ 43A l Inner circuit
(1)
(2)
(1) Gate (2) Drain
- 1 (3) Source
- 1 Body Diode
(3)
- Application
- Solar inverters
- DC/DC converters
- Switch mode power supplies
- Induction heating
- Motor drives l Absolute maximum ratings (Tvj = 25°C unless otherwise specified)
Parameter
Symbol
Drain
- source voltage
Continuous drain and source current
VGS = VGS_on
Pulsed drain current
VGS = VGS_on
Body diode pulsed forward current
Body diode surge forward current
Tc = 25°C Tc = 100°C Tc = 25°C
VGS = 0 V Tc = 25°C
Gate
- source voltage (DC)
Gate
- source surge voltage (tsurge < 300ns) Remended turn-on gate
- source drive voltage
Remended turn-off gate
- source drive voltage
Virtual junction temperature
Range of storage temperature
VDSS
ID, IS
-...
