LM2903-Q1 - General-Purpose High-Voltage Open-Drain Output Dual Comparator

RUNIC

General Description

The LM2903-Q1 is the dual comparator version, and the outputs can be connected to other open-collector outputs to achieve wired-AND relationships.

It can operate from 3.3V to 32V, and have low power consuming 55µA (TYP) per channel.

Key Features

Qualified for Automotive.

📥 Download Datasheet

LM2903-Q1 general-purpose high-voltage open-drain output dual comparator by RUNIC - Datasheet Preview

Datasheet Details

Part number	LM2903-Q1
Manufacturer	RUNIC
File Size	423.55 KB
Description	General-Purpose High-Voltage Open-Drain Output Dual Comparator
Datasheet	LM2903-Q1 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
LM2903-Q1	Automotive Dual Comparators	Texas Instruments
LM2903-N	Low-Power Low-Offset Voltage Dual Comparators	Texas Instruments
LM2903	Dual Differential Comparator	Fairchild Semiconductor
LM2903	Low power dual voltage comparator	NXP
LM2903	Low Offset Voltage Dual Comparators	ON Semiconductor

Other Datasheets by RUNIC

Part Number	Description
LM2901-Q1	General-Purpose High-Voltage Open-Drain Output Quad Comparators

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

LM2903-Q1 General-Purpose High-Voltage Open-Drain Output Dual Comparator 1 FEATURES • Qualified for Automotive Applications • AEC-Q100 Qualified with the Grade 1 • Supply Range: +3.3V to +32V • Low Supply Current 55μA (TYP) per channel at VS = 5V • Common-Mode Input Voltage Range Includes Ground • Low Output Saturation Voltage • Open-Drain Output for Maximum Flexibility • SPECIFIED UP TO +125°C • Micro SIZE PACKAGES: SOIC-8(SOP8)、 MSOP8 2 APPLICATIONS • Hysteresis Comparators • Factory Automation & Control • Industrial Equipment • Test and Measurement • Cordless Power Tool • Vacuum Robot • Wireless Infrastructure 3 DESCRIPTIONS The LM2903-Q1 is the dual comparator version, and the outputs can be connected to other open-collector outputs to achieve wired-AND relationships.
