MMBTA06
MMBTA06 is NPN Transistor manufactured by Rectron.
Features
For Switching and Amplifier Applications
plementary to MMBTA56
Power Dissipation of 300m W
High Stability and High Reliability
Mechanical Data Small Outline Plastic Package Epoxy UL: 94V-0 Mounting Position: Any
Marking: 1GM
SOT-23
Maximum Ratings & Thermal Characteristics Parameters
Collector-Base Voltage Collector-Emitter Voltage Emitter -Base Voltage Collector Current-Continuous Collector Power Dissipation Junction Temperature Storage Temperature Thermal resistance From junction to ambient
( Ratings at 25ć ambient temperature unless otherwise specified.)
Symbol
Value
Unit
VCBO
VCEO
V(%2
I&
500 m A
P&
300 m W
-55~+150
ć
Tstg
-55~+150
ć
R©-$
ć /W
Electrical Characteristics (Ratings at 25 ćambient temperature unless otherwise specified).
Parameter
Collector-base breakdown voltage Collector-emitter breakdown voltage Emitter-base breakdown voltage Collector cut-off current Collector cut-off current Emitter cut-off current
DC current gain
Collector-emitter saturation voltage Base -emitter saturation voltage Transition frequency
Symbols
V(BR)CBO V(BR)CEO V(BR)EBO...
