ISL9241 Datasheet Buck-boost Configurable Battery Charger

Manufacturer: Renesas

Overview: DATASHEET ISL9241 Buck-Boost Configurable Battery Charger with SMBus Interface and USB Power Delivery FN8945 Rev.4.01 Nov 1, 2019 The ISL9241 is a digitally configurable buck-boost battery charger that can support both Narrow Voltage Direct Charging (NVDC) and Hybrid Power Buck Boost (HPBB/Bypass) charging and switch between the modes using firmware control. Bypass mode is also supported using the firmware of the controller, which allows the adapter to provide power directly to the system.

Datasheet Details

Part number ISL9241
Manufacturer Renesas
File Size 4.22 MB
Description Buck-Boost Configurable Battery Charger
Datasheet ISL9241-Renesas.pdf

Key Features

  • using only NFETs for tablet, Ultrabook, and notebook platforms. The advanced Renesas R3™ technology provides a high, light-load efficient Charging mode. The ISL9241 takes input power from a wide range of DC power sources (such as conventional AC/DC charger adapters, USB Type-C Power ports, and travel adapters) and safely charges battery packs with up to 4-series cell Li-ion batteries. The system power can be provided from the adapter, battery, or a combination of both. The reconfigurable interna.
