RT1652 Datasheet | Richtek

Dual Mode (WPC) 5W Wireless Power Receiver and Battery Charger General Description The RT1652 is a wireless power receiver pliant with WPC Low Power v1.2 standard. The RT1652 integrates a synchronous full-bridge rectifier, a low dropout regulator, and a logic controller for control and munication. The device receives AC power from a WPC patible wireless transmitter and provides output power up to 5W, which could be used as a power supply for a charger of mobile or consumer devices. The RT1652 output can also connect to Li+ battery directly, the direct charge mode Features on running battery charger profile (PreCharge/CC/CV), to simplify the charging function design and...
