RK2928G Description
RK292X Datasheet Rev 1.1 RK292X Datasheet Preliminary Revision 1.1 Sep. 2012 Rockchips Confidential 1 RK292X Datasheet Rev 1.1 Chapter 1 Introduction RK292X is a low power, high performance processor solution for low-end tablet, Android Portable GPS and other digital multimedia applications, and integrates single-core Cortex-A9 with separately Neon and FPU coprocessor, and also with 128KB L2 Cache. Many embedded...
RK2928G Key Features
- 8KB internal SRAM
- DDR3-800, 16bits data width, 2 ranks, 1GB(max) address space per rank
- LVDDR3-800, 16bits data width, 2 ranks, 1GB(max) address space per rank
- Async/Toggle/Sync Nand Flash(include LBA Nand), 8bits data width,4 banks
- Support system boot from the following device : 8bits Nand Flash SPI interface eMMC interface
- Support system code download by the following interface: USB OTG UART2
- patible with JEDEC standard DDR3/ LVDDR3 SDRAM
- Data rates of up to 80
