ROHM Semiconductor 2SC4115S
Low Frequency Transistor
| Part No. | 2SC4115S |
|---|---|
| Datasheet | 2SC4115S Download |
| Manufacturer |  ROHM Semiconductor |
| Description | Low Frequency Transistor |
| Buy | Stock & Price |
Low Frequency Transistor (20V, 3A) 2SC4115S zFeatures 1) Low VCE(sat). VCE(sat) = 0.2V(Typ.) （IC / IB = 2A / 0.1A） 2) Excellent current gain characteristics. 3) Complements the 2SA1585S. zStructure Epitaxial planar type NPN silicon transistor zAbsolute maximum ratings (Ta=25°C) Parameter Symbol Limits Collector-base voltage VCBO 40 Collector-emitter voltage VCEO 20 Emitter-base voltage VEBO 6 Collector current 2 IC 5 Collector power dissipation PC 0.4 Junction temperature Tj 150 Storage temperature ∗ Single pulse Pw=10ms Tstg −55 to +150 Unit V V V A (DC) A (Pulse) ∗ W °C °C zDimensions(Unit:mm) 2SC4115S 4±0.2 2±0.2 3±0.2 3Min. (15Min.) 0.45+−00..1055 2.5+−00..41 5 (1) (2) (3) ROHM : SPT EIAJ : SC-72 ∗ Denotes hFE 0.5 0.45−+00..0155 (1) Emitter (2) Collector (3) Base zElectrical characteristics (Ta=25°C) Parameter Symbol Min. Collector-base breakdown voltage Collector-emitter breakdown voltage Emitter-base breakdown voltage Collector cutoff current Emitter cutoff current Collector-emit...
