2SD1733 - Power Transistor

ROHM

Key Features

1) Suitable for Middle Power Driver 2) Complementary PNP Types : 2SB1260 / 2SB1181 3) Low VCE(sat) VCE(sat)= 0.4V Max. (IC/IB=500mA/20mA) 4) Lead Free/RoHS Compliant. 2SD1898 (SC-62) Datasheet CPT3 Collector Base Emitter 2SD1733 (SC-63) lInner circuit Collector Base Emitter l.

2SD1733 power transistor by ROHM - Datasheet Preview

Datasheet Details

Part number	2SD1733
Manufacturer	ROHM
File Size	374.07 KB
Description	Power Transistor
Datasheet	2SD1733 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
2SD1733	Power Transistor	Guangdong Kexin Industrial
2SD1730	Power Transistor	Inchange Semiconductor
2SD1731	Power Transistor	Inchange Semiconductor
2SD1732	Power Transistor	Inchange Semiconductor
2SD1734	Power Transistor	Inchange Semiconductor

Other Datasheets by ROHM

Part Number	Description
2SD1757K	Power Transistor
2SD1758	Medium Power Transistor
2SD1759	(2SDxxxx) Power Transistor
2SD1759	Power transistor
2SD1760	Power Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

2SD1898 / 2SD1733 NPN 1.0A 80V Middle Power Transistor Parameter VCEO IC Value 80V 1.0A lOutline MPT3 Base Collector Emitter lFeatures 1) Suitable for Middle Power Driver 2) Complementary PNP Types : 2SB1260 / 2SB1181 3) Low VCE(sat) VCE(sat)= 0.4V Max. (IC/IB=500mA/20mA) 4) Lead Free/RoHS Compliant. 2SD1898 (SC-62) Datasheet CPT3 Collector Base Emitter 2SD1733 (SC-63) lInner circuit Collector Base Emitter lApplications Motor driver , LED driver Power supply lPackaging specifications Part No. Package 2SD1898 2SD1733 MPT3 CPT3 Package size (mm) 4540 6595 Taping code T100 TL Reel size (mm) Tape width (mm) Basic ordering unit (pcs) 180 12 1,000 330 16 2,500 Marking DF D1733 www.rohm.com © 2013 ROHM Co., Ltd. All rights reserved. 1/7 2013.05 - Rev.
