Data Sheet
100-230VAC Input/6W Output
Isolated AC/DC Converter
BP5725
Absolute Maximum Ratings
Parameter 7-pin input voltage 4-pin input voltage 7-pin input Current Maximum power Allowable maximum surface temperature
Operating temperature range Storage temperature range
Symbol VD VG ID Po
Tcmax
Limits 800 45 400
6
105
Topr −25 to +80
Tstg −25 to +105
Unit V
Vpeak mA W
°C
°C
°C
Conditions
Ambient temperature + module self-heating Tcmax
Electrical Characteristics
(Unless otherwise noted, Vi=311V, rated load Ta=25°C)
Parameter
Symbol Min.
Typ.
Max. Unit
Conditions
Output detection voltage Vod
−7.1
−7.6
−8.
BP5725 Datasheet
