TDA7850 - 4 x 50W MOSFET Quad Bridge Power Amplifier

General Description

The TDA7850 is a breakthrough MOSFET technology class AB audio power amplifier in Flexiwatt 25 package designed for high power car radio.

Key Features

  • Superior output power capability: 4 x 50W/4Ω Max. 4 x 30W/4Ω @ 14.4V, 1KHz, 10% 4 x 80W/2Ω Max. 4 x 55W/2Ω @ 14.4V, 1KHz, 10% MOSFET Output power stage Excellent 2Ω driving capability HI-FI class distortion Low output noise ST-BY Function Mute function Automute at min. supply voltage detection Low external component count:.
  • Internally fixed gain (26dB).
  • No external compensation.
  • No bootstrap capacitors On board 0.35A high side driver Flexiwatt25 (Horizontal) Fle.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TDA7850A quad bridge power amplifier STMicroelectronics
TDA7850H 4 x 50W MOSFET Quad Bridge Power Amplifier STMicroelectronics
TDA7851 4 x 48 W MOSFET quad bridge power amplifier STMicroelectronics
TDA7851L 4 x 48W MOSFET quad bridge power amplifier STMicroelectronics
TDA7854 quad bridge power amplifier STMicroelectronics

Other Datasheets by STMicroelectronics

Part Number Description
TDA7850LV 4 x 50 W quad bridge amplifier suitable
TDA7851A 4 x 48 W MOSFET quad bridge power amplifier
TDA7851F 4 x 48 W MOSFET quad bridge power amplifier
TDA7863D LOW VOLTAGE TONE CONTROL DIGITALLY CONTROLLED AUDIO PROCESSOR
TDA7211A DUAL LOW-VOLTAGE POWER AMPLIFIER

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
www.DataSheet4U.com TDA7850 4 x 50W MOSFET Quad bridge power amplifier plus HSD Features ■ Superior output power capability: 4 x 50W/4Ω Max. 4 x 30W/4Ω @ 14.4V, 1KHz, 10% 4 x 80W/2Ω Max. 4 x 55W/2Ω @ 14.4V, 1KHz, 10% MOSFET Output power stage Excellent 2Ω driving capability HI-FI class distortion Low output noise ST-BY Function Mute function Automute at min. supply voltage detection Low external component count: – Internally fixed gain (26dB) – No external compensation – No bootstrap capacitors On board 0.
